The Archive · No. 23

Around the Outside

Titanium expedition gravel · 2021 to 2024

Around the Outside
Around the Outside

About

Around the Outside was named after a line from a Malcolm McLaren record. It was the expedition bike in the range: titanium, built for loaded distance rather than speed.

The curved down tube bought clearance for the front wheel, for luggage and for a larger tyre, and the frame carried multiple bottle mounts. It was sold with drop handlebars and with flat handlebars, and could be ordered with a suspension fork.

The original version of Around the Outside (ATO) was inspired by a line from Buffalo Girls, the '80s hit by the quirky pop outlier Malcolm McLaren. A true pioneer, McLaren was the perfect inspiration for the first ATO; an elegant, stylish gravel bike designed for maximum cargo. A bike created to conquer pastures new, thanks to intelligent design and exceptional craftsmanship to the updated ATO offers all that and more. The sleek road bike aesthetic is deceptive because ATO is every bit as capable as a modern mountain bike, a machine you can rely on even when you doubt yourself. Created to cover all types of riding, every detail has been carefully considered. From the single-front gearing (42t max) preferred by modern bike-packers, to internal cable routing that keeps lines clean. We've added more mounting bosses, too, so you can load your panniers and frame packs for bigger, bolder adventures.

As with its predecessor, high-spec titanium provides the shock absorption of steel but with a lightweight comparable to carbon. The stiffness of the material also ensures excellent power transfer. Pearson's titanium bikes are made using the highest quality hand-drawn tubes available to ensure strength and agility when riding.

ATO's curved down tube allows extra clearance for both the front wheel and luggage, as well as larger tyre sizes; there's clearance for 29x2.2 inch or 27.5x2.3 inch (650x60). The frame features multiple bottle mounts (eg. on seat tube and down tube), again to better accommodate frame luggage. The expertly sculpted, cast-titanium rear wheel dropouts take their inspiration from contemporary mountain bikes, with craftsmanship that provides a class-leading strength-to-weight ratio.

GenerationsTwo generations, drop bar and flat bar
FrameHandbuilt titanium
Finishes Silver and bronze, Olive, Titanium and black
Full Specification
Groupsets offered
  • GRX815 1x
  • GRX800 1x
Wheels offered
  • DCR Wide Boy Gravel
  • Rock and Roll
  • Bump and Grind
Geometry
SIZE/CMX-SmallSmallMediumLargeX-Large
A Frame reach355375390397400
B Frame stack555578595615645
C Effective top tube510536561574586
D Seat tube length470495520540565
E Head tube length112137158179211
F Seat angle74.574.574.074.074.0
G Head angle70.570.570.570.570.5
H BB drop70.570.568.068.068.0
I Wheelbase10171047107910931107
J Chainstay length435435445445445

Still riding one?

The numbers you need when something wears out.

Thru axle, frontM12 x 1.5, 125mm
Thru axle, rearM12 x 1.75, 174mm
